JUMO PCA Communications Software PCC (B 70.9702.0) - Manual (Page 31)

31
5 Device Management
Analog
modem /
ISDN The following parameters must be selected.
TCP/IP PORT The following parameters must be selected.
Telephone number Enter the telephone
number for the required
device.
Connect via Select the modem that
will be used to make the
connection.
Communication
protocol Modbus protocol The
Modbus protocol
must be set here.
Device address 1 … 254 Device address for the
Modbus protocol.
IP address /
HOST name xxx.xxx.xxx.xxx
(Example: 192.168.0.10) Specify the IP address
or the host name of your
device. (If the host name
is used, the IP address
can be determined for
verification by clicking
"Convert host name to
IP address".)
Port number,
port name 502,
80 Port used for
communication
(protocol-dependent).
Modbus-TCP/IP -> 502
Http protocol -> 80
Communication
protocol Modbus TCP/IP,
Http protocol The
Modbus TCP/IP or
Http protocol
must be set here.
Note the port number!
