5 Device Management
30
Serial
interface
The following parameters must be selected.
CPU
Activate check
yes/no
If check is active, the
device will only be
connected if the CPU
number matches.
Path
Activate check
yes/no
If check is active, the
device will only be
connected if the USB
path matches.
Connected to
COM1, COM2
The PC interface to
which the device is
connected.
Transfer rate
9600, 19200, 38400
The transfer rate must
match the one that has
been set in the device.
Control signal
RS232
If the RS232 interface
on the device or an
interface converter with
an automatic transmit/
receive changeover is
used.
RS232 setup interface
(TTL)
If the setup interface on
the device is used.
RS422-RTS
If the RS422/485
interface on the device
is used.
Recommendation: Use
a Spectra converter with
an automatic transmit/
receive changeover.
RS422-DTR
RS485-RTS
RS485-DTR
Communication
protocol
Modbus protocol
The
Modbus protocol
must be set here.
Device address
1 … 254
Device address for the
Modbus protocol.
If the “RS232 setup
interface” is used as the
control signal, then the
device address is
ignored – it does not
have to match the
address in the device.
