N+ Wireless Modem Router
sections table of contents 1 2 3 4 5 6 8 9 10
MaNUally CoNfIgURINg NeTWoRK seTTINgs
7
Set up the computer that is connected to the cable or DSL modem
FIRST using these steps . You can also use these steps to add
computers to your Router after the Router has been set up to connect
to the Internet .
Manually Configuring Network settings in Mac os up to 9 .x
1 . Pull down the Apple menu . Select “Control Panels” and select
“TCP/IP” .
2 . You will see the TCP/IP control panel . Select “Ethernet Built-In” or
“Ethernet” in the “Connect via:” drop-down menu (1) .
3 . Next to “Configure” (2), if “Manually” is selected, your Router will
need to be set up for a static IP connection type . Write the address
information in the table below . You will need to enter this information
into the Router .
(1)
(2)
4 . If not already set, at “Configure:”, choose “Using DHCP Server” .
This will tell the computer to obtain an IP address from the Router .
5 . Close the window . If you made any changes, the following window will
appear . Click “Save” .
Restart the computer . When the computer restarts, your network
settings are now configured for use with the Router .
