12
N+ Wireless Modem Router
sections table of contents 1 2 4 5 6 7 8 9 10 3
KNoWINg yoUR RoUTeR
10 . Internet status
This unique icon shows you when the Router is connected to the
Internet . When the light is off, the Router is NOT connected to the
Internet . When the light is blinking amber, the Router is attempting
to connect to the Internet . When the light is solid blue, the Router is
connected to the Internet . When using the “Disconnect after x minutes”
feature, this icon becomes extremely useful in monitoring the status of
your Router’s connection .
Off Router is NOT connected to the Internet
Blinking Blue Router is attempting to connect to the Internet
Solid Blue Router is connected to the Internet
Blinking Amber Router is not connected to the Internet
8 . Wireless status
Off Wireless is off
Solid Blue Wireless is on
9 . adsl line status
This icon lights in blue to indicate that your Router is connected properly
to the ADSL . It turns amber when problem is detected .
Off
Router is NOT connected
to a functioning ADSL line
Solid Blue
Router is connected to
an ADSL service and
functioning properly
Blinking Amber Problem with ADSL line
