Belkin N+ PM00781EA F5D8635-4 - Manual (Page 74)

72
N+ Wireless Modem Router
sections table of contents 1 2 3 4 5 6 8 9 10 7
MaNUally CoNfIgURINg NeTWoRK seTTINgs
Manually Configuring Network settings in Windows 2000, NT, or XP
1 . Click “Start”, “Settings”, then “Control Panel” .
2 . Double-click on the “Network and dial-up connections” icon
(Windows 2000) or the “Network” icon (Windows XP) .
3 . Right-click on the “Local Area Connection” associated with your
network adapter and select “Properties” from the drop-down menu .
4 . In the “Local Area Connection Properties” window, click “Internet
Protocol (TCP/IP)” and click the “Properties” button . The following
screen will appear:
5 . If “Use the following IP address” (2) is selected, your Router will
need to be set up for a static IP connection type . Write the address
information the table below . You will need to enter this information
into the Router .
(1)
(2)
(3)
6 . If not already selected, select “Obtain an IP address automatically” (1)
and “Obtain DNS server address automatically” (3) . Click “OK” .
your network settings are now configured for use with the Router .
