2 Technical Data
Measurement range →  2, "Validity"
Accuracy
1)
0.1 F.S.
1 … 1000 F.S.
0.05% of reading
0.025% of reading
Temperature effect on zero
0.1 F.S.
1 … 1000 F.S.
10 ppm F.S./ °C
5 ppm F.S./ °C
Temperature effect on span
0.1 F.S.
1 … 1000 F.S.
10 ppm of reading / °C
5 ppm of reading / °C
Resolution, nominal 0.95 ppm F.S.
Gas type dependence none
Output signal analog (measurement signal)
Measurement range 0 … +10 V
Voltage range –2 … +10.24 V
(limited to +10.20 V)
Relationship voltage-pressure linear
Output impedance 0 Ω (short-circuit proof)
Loaded impedance >10 k Ω
Response time 2) 350 ms
Pressure unit Torr (default), mbar, Pa
(
→  16)
1)
Non-linearity, hysteresis, repeatability in the calibrated range at 25 °C
ambient operating temperature without temperature effects after
operation of 2 h.
2)
Increase 10 … 90 % F.S.R.
