tina88e1-b (2014-09) 19
Mount the gauge so that no vibrations occur. To keep
condensates and particles from getting into the measur-
ing chamber preferably choose a upright position. Install
the gauge with the damping unit in case of a horizontal
mounting orientation (
→  19).
The gauge may not be installed in a suspended mount-
ing orientation.
In case of severe vibrations at the vacuum system the
gauge should be installed with the damping unit.
If adjustment should be possible after the gauge has
been installed, be sure to install it so that the buttons
can be accessed with a pin (
→  32).
Remove the protective lid and connect the product to the
vacuum system.
Keep the protective lid.
Mounting the damping unit
DANGER
DANGER: magnetic fields
Strong magnetic fields can disturb electronic
devices like heart pacemakers or impair their
function.
Maintain a safety distance of >5 cm between the
magnet and the heart pacemaker or prevent the
influence of strong magnetic fields by antimagnetic
shielding.

Mount the damping unit (dimensions →  15).
