INFICON Cube CDGsci - Manual (Page 10)

10 tina88e1-b (2014-09)
Output signal analog (temperature / atmosphere)
Scaling sensor temperature 10 °C – 0.00 V
60 °C – 10.00 V
Temp[°C] = 10+5×Aout[V]
Scaling atmosphere 1 mbar – 0.005 V
1000 mbar – 5.00 V
ATM[Torr] =
Aout[V]/5×1000/1.33322
Switchable between temperature and atmosphere via
RS232 ASCII, REST services and web interface (
→  [1], [2],
[4]).
Identification
Resistance R
Ident
Voltage
13.2 k
Ω referenced to
supply common
≤5 V
Remote Zero Adjust
External switching contact
digital input for zero adjust-
ment (
→  32)
30 V (dc) / <5 mA (dc)
Switching functions SETPOINT 1, 2
Setting range 0 … 99% F.S. (0 … 9.9 V)
Hysteresis 1% F.S.
Relay contact 30 V (dc)/ ≤0.5 A (dc)
floating (NO)
closed p ≤ p
SP
(LED lit solid)
open p ≥ p
SP
(LED off)
Switching time ≤50 ms
Status relay
Relay contact 30 V (dc)/ ≤0.5 A (dc)
connected to supply com-
mon (pin 5)
closed measurement mode
warning
open no supply voltage
warming up
error
