tina88e1-b (2014-09) 39
4.6 Activating the Factory Setting (Factory Reset)
All user defined parameters (e.g. zero, filter) are restored to their
default values.
Loading of the default parameters is irreversible.
Loading the default parameters:

Put the gauge out of operation.

Keep the button depressed for at least 5 s while
the gauge is being put into operation (Power ON).
4.7 Diagnostic Port (RS232C Interface)
The diagnostic port permits to output the pressure
reading and all status information and to enter all settings at the
same time (
→  [3]).
When a cable is attached to the diagnostic port all other inter-
faces except the analogue outputs are automatically deactivated.
To return to normal operation after using the diagnostic port the
gauge must be power cycled.
→ "Accessories"
