1-2
Unpacking and Dimensions
5975938 BARCOREALITY 9200TCR+ 020798
310a.DRW
Battery installation in the RCU.
A battery (not yet installed to save the battery life time) is delivered inside the plastic bag with the power
cord. To install the battery, remove the battery cover on the backside of the remote control by pushing
the indicated handle a little towards the bottom of the RCU. Lift up the top side of the cover at the same
time (fig. 1).
Insert the new 9 V battery (type E-block or equivalent) in the lower compartment and connect the battery
to the contact plate.
Insert the battery into the lower compartment and put the cover back.
Note : projector address has to be programmed on the RCU before using the RCU (see chapter
'Controlling').
fig.1
fig.2
Insert here the 'Insert card
RCU' which you can cut out
on the last page of this manual.
Contact
plate
Battery
