Service Mode
10-5 5975938 BARCOREALITY 9200TCR+ 020798
Select with or
then
to return.
LAMP DRIVE MODE
SILENT
NORMAL
BOOST
Select with or
then
to return.
Lamp Run Time History
To get an overview of the different lamp run times, highlight Lamp Run
Time History by pushing the control disc up or down and press
ENTER.
A listing with the lamp serial number and the corresponding run time
will be displayed.
The actual installed lamp will be marked.
Press EXIT to return to the service mode selection menu.
SERVICE
IDENTIFICATION
CHANGE PASSWORD
CHANGE LANGUAGE
CHANGE PROJ. ADDRESS
CHANGE BAUDRATE PC
RESET LAMP RUNTIME
LAMP RUNTINE HISTORY
LAMP DRIVE MODE
MORE...
LAMP RUNTIME HISTORY
Serial No Runtime
-----------------------------------------------------
> 0111121 600 h
0110031 980 h
0110010 1000 h
-----------------------------------------------------
to return
SERVICE
IDENTIFICATION
CHANGE PASSWORD
CHANGE LANGUAGE
CHANGE PROJ. ADDRESS
CHANGE BAUDRATE PC
RESET LAMP RUNTIME
LAMP RUNTINE HISTORY
LAMP DRIVE MODE
Lamp Drive Mode
The lamp can be driven in three different modes : SILENT, NORMAL
or BOOST.
Highlight Lamp Drive Mode by pushing the control disc up or down
to select the Lamp Drive menu.
Highlight the desired lamp drive mode by pushing the control disc up
or down and press ENTER to select.
BARCO logo
The BARCO logo can be added to the image, in overlay or on a
background, on any place on the screen.
To add the BARCO logo or to change a setting in the BARCO logo
menu, highlight 'BARCO logo' by pushing the control disc up or down
and press ENTER to select.
The BARCO logo menu will be displayed on the screen. Within this
menu, three toggle settings and a shift control are available.
STATUS [ON/OFF]
ON : BARCO logo will be displayed on the screen.
OFF : No BARCO logo displayed on the screen.
BACKGROUND [ON/OFF]
ON : BARCO logo will be displayed on a black background.
OFF : BARCO logo will be displayed without any background.
SHIFT
By pushing the control disc up, down, to the left or to the right, the
BARCO logo can be positioned anywhere on the screen.
HOT KEY [TEXT/OFF]
OFF : no key on the RCU is used to display the BARCO logo.
TEXT : the TEXT key on the RCU is used to display or to remove the
BARCO logo with one single push on this key (only in operational
:mode).
SERVICE
BARCO LOGO
PANEL ADJUSTMENTS
PRESET INPUT BALANCE
I2C DIAGNOSIS
MORE...
BARCO LOGO
STATUS : ON
BACKGROUND : ON
SHIFT
HOT KEY : TEXT
Select with or
then
to return.
