C-2
Source Numbers 80 - 89 and 90 - 99
5975738 BARCOREALITY 9200TCR+ 020798
Source numbers 81 - 85
Only valid if no input module is connected to slot 81 - 85 of a RCVDS05.
The source numbers 81 - 85 correspond to the physical inputs 1 - 5 of the projector.
e.g. When slot 1 of the projector has to be selected, key in source number 81.
The relationship between the sources of slot 1 - 5 of the projector with 800 peripheral is shown in the table below.
source of slot 1 source number 81
source of slot 2 source number 82
source of slot 3 source number 83
source of slot 4 source number 84
source of slot 5 source number 85
