Instruction sheet work supports

background image

L 2216 Rev. O

05/97

IMPORTANT RECEIVING INSTRUCTIONS

Visually inspect all components for shipping damage. If any shipping damage is
found, notify carrier at once. Shipping damage is NOT covered by warranty. The
carrier is responsible for all repair or replacement costs resulting from damage in
shipment.

CONTENTS

Specifications ...................................................................................1
Safety Information ...........................................................................3
Installation

Hydraulic Connections..............................................................4
Venting ......................................................................................4

Modifications

"Air Purge" Work Supports.......................................................6
"Air Spring" Work Supports .....................................................6

Operation

Spring Advanced Work Supports..............................................7
Fluid Advanced Work Supports ................................................8
"Air Spring" Work Supports .....................................................8

Maintenance and Service .................................................................9
Troubleshooting ...............................................................................9

SPECIFICATIONS

Instruction Sheet

Work Supports

WFL / WSL 221, 222, 331, 332, 441, 442

®

MODEL

NUMBER

Capacity

@ Max. psi/bar

lbs.

(kN)

Support Plunger

Stroke
inches

(mm)

Retracted

Height
inches

(cm)

Plunger

Extended

Oil Capacity

inches

3

(cm

3

)

Support Plunger Spring Force

lbs. (kN)

Plunger

Retracted

WFL 221

5,000

0.41

3.61

1.0 - 3.25

.19

16.0 - 23.0

WFL 222

(22,3)

(10,4)

(91,7)

(4,4 - 14,0)

(3,1)

(71,0 - 102,0)

WFL 331

7,400

.53

3.87

2.0 - 6.0

.24

16.0 - 19.0

WFL 332

(32,9)

(13,5)

(98,3)

(9,0 - 26,0)

(4,0)

(71,0 - 84,0)

WFL 441

10,000

.65

4.42

1.5 - 5.0

.30

16.0 - 28.0

WFL 442

(44,5)

(16,5)

(112,3)

(6,7 - 22,0)

(4,9)

(71,0 - 124,0)

WSL 221

5,000

0.41

3.61

1.0 - 3.25

.01

16.0 - 23.0

WSL 222

(22,3)

(10,4)

(91,7)

(4,4 - 14,0)

(0,2)

(71,0 - 102,0)

WSL 331

7,400

.53

3.87

2.0 - 6.0

.01

16.0 - 19.0

WSL 332

(32,9)

(13,5)

(98,3)

(9,0 - 26,0)

(0,2)

(71,0 - 84,0)

WSL 441

10,000

65

4.42

1.5 - 5.0

.01

16.0 - 28.0

WSL 442

(44,5)

(16,5)

(112,3)

(6,7 - 22,0)

(0,2)

(71,0 - 124,0)
