Cornet Installation Guide Technical Specifications
MAN-CORIG (Ver. 1.502)
www.elmomc.com
67
1.23.1. Digital Input Interfaces (on the COMMITTED I/O port)
Feature Details Connector Location
Type of input Optically isolated
Single ended
PLC level
•
•
FEEDBACK B
FEEDBACK A
ANALOG INPUTS
COMMITTED I/O
COMM.2
GENERAL I/O
COMM.1
COR0001A
Input current
Ω
−
=
2500
5 . 6 V Vin
Iin
* Iin = 2.2 mA @ Vin = 12 V
Input current for
high speed
inputs
Ω
−
=
1250
5 . 6 V Vin
Iin
* Iin = 4.4 mA @ Vin = 12 V
High-level input
voltage
12 V < Vin < 30 V, 24 V typical
Low-level input
voltage
0 V < Vin < 6.5 V
Minimum pulse
width
> 4 x TS, where TS is sampling time
Execution time
(all inputs):
the time from
application of
voltage on input
until execution
is complete
If input is set to one of the built-in functions —
Home, Inhibit, Hard Stop, Soft Stop, Hard and Soft
Stop, Forward Limit, Reverse Limit or Begin —
execution is immediate upon detection: 0 < T < 4 x
TS
If input is set to General input, execution depends
on program. Typical execution time: ≅ 0.5 msec.
D
IG
IN
PU
T
2.5
K
R
ele
va
nt
In
pu
t R
etu
rn
Digital Input Schematic
High-speed
inputs -
minimum pulse
width, in high-
speed mode
T < 5 µsec
Notes:
Home mode is high-speed mode and can be used
for fast capture and precise homing.
High speed input has a digital filter set to same
value as digital filter (EF) of main encoder.
Highest speed is achieved when turning on
optocouplers.
DIGITAL INPUTS
