Cornet Installation Guide Technical Specifications
MAN-CORIG (Ver. 1.502)
www.elmomc.com
59
1.18. Power Ratings
Feature
Un
it
s
1/
230
3/
230
5/23
0
7/23
0
9/23
0
1/46
0
3/46
0
6/46
0
Minimum supply voltage VAC 60 140
Nominal supply voltage VAC 1 x 115, 1 x 230, 3 x 230 3 x 400, 3 x 460
Maximum supply voltage VAC 1 x 270 or 3 x 270 3 x 505
Maximum continuous
power output
W 420 1050 1500 2100 2700 800 2000 3400
Efficiency at rated power
(at nominal conditions)
% > 93
Auxiliary supply voltage VDC 24 ± 15%
Auxiliary power supply VA 20
Amplitude sinusoidal/DC
continuous current
A 1.4 3.5 5 7 9 1.4 3.5 6
Sinusoidal continuous RMS
current limit (Ic)
A 1 2.5 3.5 5 6.4 1 2.5 4.3
Peak current limit A 2 x Ic
Built-in shunt (peak power) kW 2.4 1.1 3.4 3.4
Weight kg (lbs) 1.1 kg (2.4 lbs)
Dimensions mm
(in)
180 x 123 x 75 (7.1" x 4.8" x 3")
Digital in/Digital
out/Analog in
10/6/2
Mounting method Wall mount (Bookshelf) or DIN rail
