Notice
This guide is delivered subject to the following conditions and restrictions:
a.
This guide contains proprietary information belonging to Elmo Motion Control Ltd.
Such information is supplied solely for the purpose of assisting users of the Cornet
servo drive in its installation.
b. The text and graphics included in this manual are for the purpose of illustration and
reference only. The specifications on which they are based are subject to change
without notice.
c. Elmo Motion Control and the Elmo Motion Control logo are trademarks of Elmo
Motion Control Ltd.
d. Information in this document is subject to change without notice.
Document no. MAN-CORIG (Ver. 1.502)
Copyright  2014
Elmo Motion Control Ltd.
All rights reserved.
Catalog Number
Nominal AC
Operating Voltage
Continuous Current
(Amps)
Version :
Blank = Standard
A = Advanced
Feedback:
Blank = Incremental
Encoder
and/or Halls
R = Resolver
COR- A X/YYY R
T = Tachometer &
Potentiometer
I = Interpolated
Analog
Encoder
Q =
Encoder
Absolute
Revision History
Version Date Release
1.0 Initial release
Ver. 1.2 Apr 2008 Updated Power Ratings Table in Section 1.18
Ver. 1.3 Aug 2008 Added Section 1.13.7.4: Differential Pulse-and-Direction
Input
Ver. 1.4 Mar 2010 MTCR 07-009-56: Added note to Section 1.13.8.1
Ver. 1.5 July 2012 Formatted according to new template
Ver. 1501 Feb 2012 Added a caution and recommendation on the type of
cleaning solution to use for the Elmo unit.
Ver. 1502 July 2014 General format updates
