speciFicatiOns
ATX10 and AC100
OpeRATing VOlTAge—
24 Vdc nominal; Operating range is 9 to 30 Vdc.
Um=250 V (Intrinsic Safety Rating).
pOweR COnSumpTiOn—
AC100: 1.25 watts @ 9 Vdc
1.25 watts @ 24 Vdc
1.25 watts @ 30 Vdc.
ATX10: 0.75 watts @ 9 Vdc
1.25 watts @ 24 Vdc
1.75 watts @ 30 Vdc.
TempeRATuRe RAnge—
Operating: –55°C to +75°C (–67°F to +167°F)
Storage:
–55°C to +85°C (–67°F to +185°F).
HumiDiTy—
5 to 95% RH, non-condensing (Det-Tronics verified).
ingReSS pROTeCTiOn—
IP66, NEMA/Type 4X.
COnDuiT enTRieS—
3/4” NPT or M25.
enClOSuRe mATeRiAl—
316 stainless steel, electropolished.
SHipping weigHT—
AC100:
6.2 pounds (2.8 kilograms).
ATX10:
11.5 pounds (5.2 kilograms).
DimenSiOnS—
See Figure 1.
wARm-up—
Upon power-up, device performs self-test and
initialization procedures, then automatically enters
normal operating mode.
wARRAnTy—
3 years.
CeRTiFiCATiOn—
For complete approval details, refer to the appropriate
Appendix:
FM
APPROVED
®
Appendix A - FM
Appendix B - CSA
Appendix C - ATEX
Appendix D - IECEx
Appendix E - Maritime
SIL Approval - IEC 61508
Certified SIL 2 Capable.
For specific information regarding SIL, refer to the
Safety Reference Manual (form 95-8658) for details.
eleCTRO-mAgneTiC COmpATibiliTy—
EMC Directive 2004/108/EC
Emissions: EN61000-6.3
EN61000-6.4
Immunity: EN61000-6.1
EN61000-6.2
AC100 only
ACOuSTiC—
Dynamic Range: 40 to 139 dB
Ultrasonic Band: 24 individual bands over the
ultrasonic frequency range (20 kHz
to 80 kHz).
SelF-DiAgnOSTiC TeST (AiC)—
Automatic acoustic integrity check performed once
every 10 (factory default) minutes.
