Det-Tronics ATX10 Transmitter - Manual (Page 28)

2.5 95-8657 26
trOuBlesHOOtinG
If a Fault condition is indicated by the LED on the ATX10
faceplate, the nature of the fault can be determined by
navigating to the STATUS INFO MENU. See Table 3 for
additional information.
Table 3—Troubleshooting guide
Fault Indication Description Corrective Action
Ai FAulT
AiC has failed. microphone or emitter is
degraded.
provide data log information to Det-Tronics for analysis.
SD ADViSORy
SD memory module has an issue
that requires intervention via the SD
ADViSORy menu.
SD card is out-of-sync with the ATX10 on-board flash. it
will be necessary to either uplOAD the data to the SD
card or DOwnlOAD the data to the ATX10 if the SD
card contains valid data (via SD ADViSORy menu).
SnSR HDwR FAulT Hardware fault on the AC100 Sensor. Return to factory for repair.
TX HDwR FAulT
Hardware fault on the ATX10
Transmitter.
Return to factory for repair.
VOlTAge FAulT
Detector operating voltage is out of
tolerance.
Check output voltage at the power source. Check power
wiring to the detector.
