2.5 95-8657 31
appenDix c
ATEX APPROvAL DESCRIPTION
EN Standards:
EN60079-0: 2012
Electrical apparatus for explosive atmospheres, General Requirements
EN60079-1: 2007 Electrical apparatus for explosive atmospheres, Flameproof enclosure “d”
EN60079-11: 2012 Explosive atmospheres Equip protection by Intrinsic Safety
EN60079-31: 2009 2008 Explosive atmospheres Equip. Dust Ignition Protection by enclosure “t”
EN60529:2004 Degrees of Protection Provided by Enclosures (IP Code)
ATEX Special Conditions for Safe Use (‘X’):
AC100
• The AC100 Acoustic Sensor must always be installed with the detection head pointing down vertically.
• The AC100 Acoustic Sensor must only be installed in areas where there is a low risk of mechanical damage.
• The AC100 is only to be used connected to the ATX10 Acoustic Transmitter or Model STB Sensor Termination Box.
ATX10
• The ATX10 must only be installed in areas where there is a low risk of mechanical damage.
Additional Safety Notes:
• The following warning is on the product: Warning: Do not open when an explosive gas atmosphere may be
present. For ambient temperature above 60°C use field wiring suitable for maximum ambient temperature. For
temperature below –10°C use suitable field wiring for the lowest temperature.
• Cable, bushings and the conduit entries shall be of a flameproof type already certified according to relevant
ATEX standard, rated IP66, so the protection principle employed will not be impaired.
• Unused conduit entries shall be closed using flameproof stop plugs certified for the conditions of use (IP66
minimum). The stop plugs should be removable only with the aid of a tool.
• Shielded cable is required.
AC100
DEMKO 12 ATEX 1263479X
0539
FM
APPROVED
®
II 2 G
II 2 D
Ex d ib IIC T4 Gb
Ex tb IIIC T80°C Db
Tamb: –55°C to +75°C
IP66
ATX10
DEMKO 12 ATEX 1263925X
0539
FM
APPROVED
®
II 2 G
II 2 D
Ex d IIC T6 Gb
Ex tb IIIC T80°C Db
Tamb: –55°C to +75°C
IP66
