Despatch Protocol Controller - Manual (Page 39)

33
Program Mode
Program Mode Outline
Display Description
PROGRAM
Hi-Limit
HL
PROFILES
PRO-
SEG-
RAMP
EVENTS
E-1
E-2
E-3
TEMP
SOAK
EVENTS
E-1
E-2
E-3
SOAK-DEV
+/-
GOTO
REPEAT
TIMES
HOLD
YES
NO
Select Program mode.
Hi-Limit for Program mode
Enter high limit temperature (+ or - keys).
Enter profile number (1-8).
Segment number of profile (1-6)
Ramp time entered
Event status for ramp time
Event 1 status (ON or OFF)
Event 2 status (ON or OFF)
Event 3 status (ON or OFF)
Ramp ending temperature
Soak period of ramp ending temperature
Event status for soak period
Event 1 status (ON or OFF)
Event 2 status (ON or OFF)
Event 3 status (ON or OFF)
Soak-Deviation limit for profile (Also assured soak limit)
Enter soak-deviation limit.
Enter profile to GOTO
End = Move to REPEAT TIMES command
1 = GOTO profile 1
2 = GOTO profile 2
:
8 = GOTO profile 8
Enter number of recursions (1-99)
1 = Execute profile 1 times
2 = Execute profile 2 times
:
99 = Execute profile 99 times
Hold at last setpoint?
Hold at last setpoint indefinitely.
Holds event outputs at last value.
No hold at last setpoint.
Event outputs turn OFF.
Notes on the Program mode:
