Despatch Protocol Controller - Manual (Page 23)

17
NOTE: The SOAK-DEV limit is
also the assured soak limit. This
means that the soak times will not
begin until the process
temperature is within the SOAK-
DEV parameter.
NOTE: If the Protocol is in a hold
condition, pressing the Reset key
will display that the control is in
segment 7 (HOLD).
5. Enter the Soak-Deviation.
a. Press – key until SOAK-DEV is
displayed.
b. Press a key. The symbol +/- will be
displayed.
c. Use the + or - keys to enter the soak deviation limit.
6. Enter the next profile to continue to, or end profile.
a. Press – key. GOTO will be displayed.
b. Use the + or - keys to enter the profile number to continue to. Select End
to stop at the end of this profile. For continuous profiles enter the same
number of the profile that is currently being programmed.
7. Enter the number of profile recursions.
a. Press – key. REPEAT will be displayed.
b. Press – key. TIMES will be displayed.
c. Use the + or - keys to enter the number of times to complete the profile
being programmed (1 - 99).
8. Enter the profile end condition. The hold
command is contingent on the final segment
of the last profile to be run only.
a. Press – key. HOLD will be displayed.
b. Use the + or - keys to select YES or
NO.
C
Selecting YES will hold at last setpoint. The event outputs will be
held at their last value.
C
Selecting NO will not hold at last setpoint. The event outputs will
be turned off.
