Dakota Ultrasonics
28
RESTORE SETUPS: Enables the user the ability to restore the setups currently
saved on a PC to an CMX
DL
via RS232 port. Refer the help section of the CMX
DL
DakView software for a complete electronic manual.
BACKUP DATA: Enables the user the ability to backup grids or sequential log files
currently stored in the CMX
DL
to a PC via RS232 port. Refer the help section of the
CMX
DL
DakView software for a complete electronic manual.
RESTORE DATA: Enables the user the ability to restore grids or sequential log files
currently saved on a PC to an CMX
DL
via RS232 port. Refer the help section of the
CMX
DL
DakView software for a complete electronic manual.
ABOUT: Provides the user with Dakota Ultrasonics contact information and the
CMX
DL
software version. Refer the Dakota Ultrasonics web site for information on
the latest firmware versions available for download.
3.10 CLR (clear) Key
The primary functions of the CLR key, is to clear a measurement from a grid or
sequential log files cell location or set obstruct, and backspace in an Alpha Edit Box.
If a user has already saved a measurement and B-Scan to a cell location, use this
key to clear the measurement at any time.
3.11 MEAS (measurement mode) Key
The ME AS key puts the CMX
DL
into it’s primary mode of operation. In this mode, the
user has a complete view of the LCD.
3.12 OK Key
The primary function of the OK key is confirmation of a change or selection. If the
CMX
DL
is displaying a grid log, the OK key toggles an advance to row number option.
3.13 ESC Key
The ESC key is used in the MENU, MEAS, and EDIT functions as a back or escape
function. If the CMX
DL+
is displaying a grid or sequential log, the OK key toggles the
display options: Digits and B-Scan views.
