CHAPTER 5 MAINTENANCE
5-13
C C l l e e a a n n i i n n g g
Clean the printer exterior and interior periodically with a dry soft cloth. When
you replace the toner bottle, be sure to clean the printer interior with a dry
soft cloth. If the printed page gets stained with Toner, clean the printer
interior with a dry soft cloth.
Warning
• Turn off the printer power and allow it to cool down before cleaning.
!
Cleaning the Paper feed roller
If the paper feed rollers are dirty with paper dust, the paper may not feed
correctly or paper jam. In this case, clean the paper feed rollers. Follow
these steps to clean the paper feed rollers in standard paper tray 1 and
paper tray 2.
☛ ☛ ☛ ☛ 1.
Turn off the printer power.
☛ ☛ ☛ ☛ 2.
Slide Paper tray 1 and Paper tray 2 out until they stop. Raise the front end
slightly and pull the paper trays forward to remove them from the printer.
ZAEP060E
Fig. 5-23
