CHAPTER 4 OPTIONS
4-61
H H D D D D ( ( H H a a r r d d D D i i s s k k D D r r i i v v e e ) )
By installing an optional HDD, you can save multiple print jobs onto it. You
can also select your print job and re-print it through the network.
☛ ☛ ☛ ☛ 1.
Confirm that the box contains the following items.
Fig. 4-100
1. HD-6G/HD-EX
2. Hard disk cables (2) [Use the longer one]
3.
Shoulder screws (4)
4.
Screws (4)
5. Setup guide
☛ ☛ ☛ ☛ 2.
Turn off the printer and unplug the power cord from the AC outlet.
Disconnect the interface cable from the printer.
☛ ☛ ☛ ☛ 3.
Use a screwdriver to remove the six screws, and remove the printer board
cover.
✒
Note
The removed cover and screws are required in step 9.
Fig. 4-101
1
2
3
4
5
