Brother T74 User Manual
Page 79
Troubleshooting and Maintenance
73
MAINTENANCE
5
Remove the white gear and spools from the ends of the used cardboard cores. Then insert them
into the same positions in the new cores.
6
Slip the upper left cardboard core onto the blue gear of the cartridge and insert the rolls into the
cartridge holders.
7
Turn the upper right white spool clockwise to tighten the ribbon, as shown.
White Spool
White Gear
New Ribbon
White Spool
Blue Gear
Shiny side is face down
