9.5.1.2 Operating Transmitter Display
In operating mode the display screen is split into three distinct
portions. The majority of the screen is devoted to a 2-line
measurement display as illustrated below. The bottom portion of the
screen will display status and configuration information.
Figure 52 Operating Transmitter Display
9.5.1.2.1 Line 1 / Line 2
Either line may be configured to display any of the values listed below.
Value Units
Gas Volume Fraction Percent (%)s
Speed Of Sound Feet per Second (fps) or Meters per Second (mps)
Blank Line is blank
Table 7 Line 1 and Line 2 Values
9.5.1.2.2 Status Line
The code for information in the status line shown in Figure 52 are
defined as follows:
ID Characters Description Values
S 20 Status Messages See Status Messages Table below
Q 11 Quality Field See Quality Field Message Table below
M 4 Mode See Operating Mode Message Table below
C 1 Communications E – Ethernet or S – Serial
H 1 Hart Activity H – Hart Message received or [blank] – No Activity
W 1 Write Protect W – Write Protected or
[blank] – Not Write Protected
E 1 Event Log Updated ! – Event Log Updated or [blank] – No change to
Event Log since last check
A 1 Activity |/-\ (Cycle changes indicate activity)
Table 8 Status Line Code
G
V
F
2.016 %
S
O
S
351.7 ft/s
SSSSSSSSSSSSSSSSSSSS QQQQQQQQQQQ MMMM CHWEA
Gas Volume
Fraction
Speed Of
Sound
Line 1
Line 2
Status Line
