1 - 16 System Map: Right & Rear Views
Quick Start Guide
1
System Map: Right & Rear Views
Figure 1 - 7
Right & Rear Views
1. Microphone-In
Jack
2. Headphone-Out
Jack
3. 1 *USB 2.0 Port
(Model A)
OR
2 *USB 2.0 Ports
(Model B)
4. Optical Device
Drive Bay (for CD/
DVD Device)
5. Security Lock Slot
6. Battery
4
2
5
1
6
W255EU
3
4
5
2
1
3
3
Model A
Model B
Battery Information
Always completely discharge, then fully charge, a new battery before using it. Completely
discharge and charge the battery at least once every 30 days or after about 20 partial dis-
charges.
