chiliGREEN W550SU2 - Manual (Page 255)

Specifications
Specifications D - 3
D
Interface
Model A:
One USB 2.0 Port
Model B:
Two USB 2.0 Ports
All Models:
Two USB 3.0 Ports
One External Monitor Port
One HDMI-Out (High-Definition
Multimedia Interface) Port (with HDCP)
One Headphone-Out Jack
One Microphone-In Jack
One RJ-45 LAN Jack
One DC-In Jack
Card Reader
Embedded Multi-In-1 Card Reader
- MMC/ RS MMC
- SD/ Mini SD / SDHC/ SDXC
- MS/ MS Pro/ MS Duo
Note: Some of these cards require PC
adapters that are usually supplied with
the cards.
Slot
Two Mini-Card Slots:
Slot 1 for Half Size Mini-Card WLAN
Combo Module with PCIe & USB
Interfaces
Slot 2 for Full Size Mini-Card mSATA
SSD with SATA Interface
OR
for Full Size Mini-Card 3G Module with
USB Interface (Factory Option)
Communication
Built-In 10/100/1000Mb Base-TX
Ethernet LAN
Intel® Wireless-N 7260 (2*2 802.11 b/g/n)
Half Mini-Card PCIe WLAN
+ Bluetooth
Combo Module (Factory Option)
3rd Party Combo WLAN (802.11b/g/n)
and Bluetooth v4.0+LEHalf Mini-Card
Module with PCIe Interface (Factory
Option)
3rd Party WLAN 802.11b/g/n Half Mini-
Card Module (Factory Option)
1.0M HD Video Camera Module with
USB interface (Factory Option)
UMTS/HSPDA OR UMTS/HSPDA+
based 3G Module with Mini-Card
Interface (Factory Option)
Quad-band GSM/GPRS (850 MHz, 900
MHz, 1800 MHz, 1900 MHz)
UMTS WCDMA FDD (2100 MHz)
Note that UMTS modes CAN NOT be
used in North America
Power Management
Supports Wake on LAN
Supports Wake on USB
Supports Wake on RTC Alarm (AC Mode
Only
Power
Full Range AC/DC Adapter
AC input 100 - 240V, 50 - 60Hz,
DC Output 19V, 2.1A (40 Watts)
Removable 6 Cell Smart Lithium Ion
Battery Pack 48.84WH
Removable 6 Cell Smart Lithium Ion
Battery Pack 62.16WH (Factory Option)
