System Map: LCD Panel Open - Model B
Figure 1 - 3
LCD Panel Open -
Model B
1. Built-in PC Camera
(Optional)
2. PC Camera LED
3. Built-In Microphone
4. LCD
5. Power Button
6. Keyboard
7. Touchpad &
Buttons
7
Touchpad Buttons
(valid operation area)
3
5
1
7
4
6
Note that the Touchpad and Buttons valid operational area is that indicated within the red dotted lines
indicated on the right.
2

Wireless Device
Operation Aboard
Aircraft
The use of any portable
electronic transmission
devices aboard aircraft is
usually prohibited. Make
sure the WLAN & Blue-
tooth module(s) are OFF
if you are using the com-
puter aboard aircraft by
putting the system in to
Airplane Mode (see
Table 1 - 3, on page 1 -
13
).
