Features & Components
2 - 12 Recording Audio
2
Recording Audio
(Models A & B only)
The
audio record hot key button allows you to record audio from either the built-
in microphone, or from a microphone connected to the microphone-in jack. To
record on the computer, setup the audio recording options in Windows as follows
(see
Figure 2 - 8 on page 2 - 13
).
1.
Click Start, and click Control Panel (or point to Settings and click Control Panel).
2.
Click Sound (Hardware and Sound).
3.
Click Recording (tab).
4.
Right-click Microphone (VIA High Definition Audio) and make sure the item is not
disabled (if you wish to record from the internal microphone make sure that the
Front Mic is not disabled).
5.
Double-click Microphone/Front Mic (or select Properties from the right-click menu).
6.
Click Levels (tab), and adjust the Microphone/Front Mic slider to the level
required.
7.
Click OK and close the control panels.
8.
Press the audio record button
to begin the recording process (the record icon
will flash in the top left of the screen).
9.
Press the
audio record button again to stop the recording process (the record
icon will disappear from the top left of the screen).
10. The recorded audio file (in .wav format) will appear in the wav folder in the Users
folder (
C:\Users\wav
).
11. Double-click the file to playback the recorded audio.
Model C Computers
Note that Model C com-
puters do not support
the audio record or cam-
era zoom hot keys func-
tions.
Model C computers do
not display the visual in-
dicators illustrated in
Table 2 - 2, on page 2 -
10
.
You may configure the
Application Hot Key
(for one application) as
outlined in
