System Map: LCD Panel Open Models A & B 1 - 7
Quick Start Guide
1
System Map: LCD Panel Open Models A & B
Figure 1 - 2 - Top View with LCD Panel Open Models A & B
2
6
1
8
9
4
1.
Optional Built-In PC Camera
2.
LCD
3.
Speakers
4.
Power Button
5.
Hot Key Buttons
6.
Hot Key Buttons (Record
Audio & PC Camera Zoom)
7.
Keyboard
8.
TouchPad and Buttons
9.
Built-In Microphone
10. LED Indicators
11. Fingerprint Reader
(Optional for Model B
Computers only)
7
3
3
5
Wireless Device
Operation Aboard
Aircraft
The use of any portable
electronic transmission de-
vices aboard aircraft is usu-
ally prohibited. Make sure
the module(s) are OFF if
you are using the computer
aboard aircraft.
Use the key combinations to
toggle power to the WLAN/
Bluetooth modules, and
check the LED indicator
icon to see if the modules
are powered on or not (see
Table , on page 1 - 9
/
).
10
10
11
