CHAMPION EUCC Series - Manual (Page 85)

77
C4 Wash with Scrap Basket Electric Tank Heat Installation
1 100097 SCREW,TRUSS HEAD,10-32 x 1/2 SS T 2
2 100100 SCREW,ROUND HEAD,8-32 x 1/4 SS T 2
3 100154 HEX PLAIN NUT,5/16-18 SST 12
4 100547 LOCKNUT,1/2" NPT,SST 2
5 100740 HEX HEAD,5/16-18 X 1 SST 12
6 102376 WASHER,FLAT,5/16x3/4x.06 SST 24
7 104985 HEX PLAIN NUT,10-32 SST 4
8 106013 WASHER,LOCK,5/16 SPLIT,SST 12
9 107033 WASHER,FLAT,.208X.438X.047 SST 8
12 107966 HEX GRIP NUT,10-32 SST W/NYLON 4
13 108345 GASKET,HEATER/STANDPIPE 3
14 109069 THERMOSTAT,CONTROL,WITH CAPILLARY 1
15 109165 WELD-STUD,10-32 X 3/4 LG.SST 4
16 109682 THERMOSTAT COVER BOX 1
17 110561 THERMOSTAT,HI-LIMIT,WITH CAPILLARY 1
18 110837 ELBOW,1/2" CONDUIT,SEALTITE 1
19 201041 WASHER,SPACER,7/8x1 3/16x1/8 NP 2
20 314102 BOX,DUAL THERMOSTAT 1
21 453122 HEATER BOX ASSY,C4+BKT,ELEC 1
107846 TANK HEATER, RICA 10KW 480V 3PH 2
111120 TANK HEATER, RICA 10KW 575V 3PH 2
107844 TANK HEATER, RICA 10KW 240V 3PH 2
11 107951 TANK HEATER, RICA 10KW 208V 3PH 2
10 107839 TANK HEATER, RICA 5KW 208V 3PH 1
107840 TANK HEATER, RICA 5KW 240V 3PH 1
107842 TANK HEATER, RICA 5KW 480V 3PH 1
111123 TANK HEATER, RICA 5KW 575V 3PH 1
