CHAMPION EUCC Series User Manual
Page 197
189
Control Cabinet (From S/N J2098 up to J08102541)
1
108122
Contactor, Motor 12A, Drive
1
2
108122
Contactor, Motor 12A, Prewash
1
3
108122
Contactor, Motor 12A, Wash
1
4
108122
Contactor, Motor 12A, Rinse
1
5
108122
Contactor, Motor 12A, Eco Rinse
1
6
108122
Contactor, Motor 12A, Steam Blower Dryer
1
7
110804
Starter, Motor 1/2HP Drive 208-240/60/3
1
---
110803
Starter, Motor 1/2HP Drive 380-415/60/3
1
---
110803
Starter, Motor 1/2HP Drive 480/60/3
1
---
110802
Starter, Motor 1/2HP Drive 575/60/3
1
8
110805
Starter, Motor 1HP Prewash 208-240/60/3
1
---
110804
Starter, Motor 1HP Prewash 380-415/60/3
1
---
110804
Starter, Motor 1HP Prewash 480/60/3
1
---
110803
Starter, Motor 1HP Prewash 575/60/3
1
---
112691
Starter, Motor 2HP Prewash 208-240/60/3
1
---
110805
Starter, Motor 2HP Prewash 380-415/60/3
1
---
110805
Starter, Motor 2HP Prewash 480/60/3
1
---
112692
Starter, Motor 2HP Prewash 575/60/3
1
---
110807
Starter, Motor 3HP Prewash 208-240/60/3
1
---
110806
Starter, Motor 3HP Prewash 380-415/60/3
1
---
110806
Starter, Motor 3HP Prewash 480/60/3
1
---
110805
Starter, Motor 3HP Prewash 575/60/3
1
9
110807
Starter Motor 3HP Wash 208-240/60/3
1
---
110806
Starter Motor 3HP Wash 380-415/60/3
1
---
110806
Starter Motor 3HP Wash 480/60/3
1
---
110805
Starter Motro 3HP Wash 575/60/3
1
10
110807
Starter Motor 3HP Power Rinse 208-240/60/3
1
---
110806
Starter Motor 3HP Power Rinse 380-415/60/3
1
---
110806
Starter Motor 3HP Power Rinse 480/60/3
1
---
110805
Starter Motor 3HP Power Rinse 575/60/3
1
11
110803
Starter Motor 1/4HP Auxiliary Rinse 208-240/60/3
1
---
110802
Starter Motor 1/4HP Auxiliary Rinse 380-415/60/3
1
---
110802
Starter Motor 1/4HP Auxiliary Rinse 480/60/3
1
---
110806
Starter Motor 1/4HP Auxiliary Rinse 575/60/3
1
12
110807
Starter Motor 2HP Steam Blower Dryer 208-240/60/3
1
---
110806
Starter Motor 2HP Steam Blower Dryer 380-415/60/3
1
---
110805
Starter Motor 2HP Steam Blower Dryer 480/60/3
1
---
110805
Starter Motor 2HP Steam Blower Dryer 575/60/3
1
13
111153
Block, fuse
2
14
111823
Fuse, 6A 208-240/60/3
2
15
111822
Fuse, 5A 380-415/60/3
2
16
111821
Fuse, 3A 460-480/60/3 575/60/3
2
17
103310
Lug, Wire Ground (Use with 115A Terminal Block)
1
---
103311
Lug, Wiire Ground (Use with 200A or 310A Terminal Block)
1
Item
No.
Part
No.
Qty.
Description
(Parts continued on next page)
