CHAMPION EUCC Series User Manual
Page 145
137
Steam Injector Heat Installation Auxiliary Rinse RL
1
100003
HEX PLAIN NUT,1/4-20 SST
1
2
100007
SCREW,TRUSS HEAD,10-32 x 3/8 SST
3
3
100134
ELBOW,STREET,1NPT X 90,MI
2
4
100154
HEX PLAIN NUT,5/16-18 SST
4
5
100516
STREET ELBOW,1/2"NPT X 90,SST
1
6
100547
LOCKNUT,1/2" NPT,SST
1
7
100740
HEX HEAD,5/16-18 X 1 SST
4
8
100854
CHECK VALVE,1" NPT BRONZE
1
9
102376
WASHER,FLAT,5/16x3/4x.06 SST
8
10
102393
BUSHING,REDUCING,3/4"NPTx1/2"NPT,SST
1
11
102554
UNION,3/4"NPT, SST
1
12
105739
ELBOW,REDUCING,1"NPT X 3/4"NPT X 90,M.I.
1
13
105780
UNION,1"NPT, MALLEABLE IRON
2
14
105847
NIPPLE,1"NPT X CLOSE,B.I.
2
15
105861
NIPPLE,1"NPT X 6" LG.,B.I.
1
16
106013
WASHER,LOCK,5/16 SPLIT,SST
4
17
106482
WASHER,LOCK,1/4 SPLIT,SST
1
18
106486
WASHER,LOCK,#10 SPLIT,SST
2
19
106789
NIPPLE,1"NPT X 3 1/2" LG.,B.I. EUCCW
1
---
105847
NIPPLE,1"NPT X CLOSE, LG.,B.I. EUCC
1
20
107033
WASHER,FLAT,.208X.438X.047 SST
4
21
107136
SCREW,HEX HEAD,10-32 x 3/8 SST
2
22
107966
HEX GRIP NUT,10-32 SST W/NYLON
4
23
108345
GASKET,HEATER/STANDPIPE
1
24
109069
THERMOSTAT,CONTROL,WITH CAPILLARY
1
25
109969
NIPPLE,1"NPT X 3 3/4" LG.,B.I. EUCCW
1
---
105850
NIPPLE,1"NPT X 2" LG.,B.I. EUCC
1
27
111371
NIPPLE,TOE,1"NPT X 7"LG.,SST
1
28
112259
NIPPLE,1/2"NPT X 4"LG.,SST
1
29
201041
WASHER,SPACER,7/8x1 3/16x1/8 NP
1
30
201110
STEAM INJECTOR
1
31
307404
FLANGE WELDMENT,STEAM,UCC/CW
1
32
322811
HEATER BOX WELDMENT,E2-B
1
33
322812
COVER,HEATER BOX,E2-BKT
1
34
323430
BRACKET, THERMOSTATS,USN72,44CR
1
35
331176
BRACKET,STEAM INJECTOR NIPPLE,C3/C4
1
36
601862
PIPING ASSY,STEAM INJECTOR,E2 RL EUCCW
1
---
601873
PIPING ASSY,STEAM INJECTOR,E2 RL EUCC
1
26
110005
VALVE, 1" ASCO (NO LONGER AVAILABLE)
1
110007
REPAIR KIT, 1" ASCO VALVE # L8220G007 ONLY
A/R
---
114800
VALVE, 1" ASCO STEAM ASCO # L8220G410
1
114830
REPAIR KIT, 1" ASCO VALVE # L8SS0G410 ONLY
A/R
