Swing-out Door Assembly E2 R-L /B30 L-R
1 100141 Hex Grip Nut, 1/4-20 SST Ctr. Lock 2
2 100142 Hex Grip Nut, 5/16-18 SST Ctr. Lock 1
3 100734 Bolt, Hex Hd., 1/4-20 x 1/2" SST 2
4 100735 Bolt, Hex Hd., 1/4-20 x 5/8" SST 13
5 100771 Set Screw, 1/4-20 x 1/4" Lg. Cup Point SST 2
6 104925 Washer, Flat 1/4" x 1" x .06" SST 1
7 106026 Washer, Flat 1/4" x 5/8" x .06" SST 6
8 106482 Washer, Lock 1/4" Split Lock SST 13
9 107033 Washer, Flat, .208" x .438" x .03" SST 4
10 108954 Hex Grip Nut, 6-32 SST w/nylon 4
11 113719 Reed Switch, Aleph 1
12 113937 Magnet, Reed Switch 1
13 114705 Bushing, Door Pin, Hinged Door 2
14 114706 Roller, Door Closure, Swing-out Door 1
15 114826 Pin, Spiral, .187" Dia. x .625" Lg. 2
16 114827 Bolt, Hex HD., 5/16" x 3" SST 1
17 207003 Tube, 1/2" OD x 2-3/4" Lg. 1
18 207004 Rod, Door Pivot, Single EUC Swing-out Door 1
19 333324 Hinge, Flag Hood Side, Swing-out Door 2
20 333326 Hinge, Weldment, LH Top Swing-out Door 1
21 333327 Bracket, Door Roller, Swing-out Door 1
22 333537 Hinge Weldment, Swing-out, Bottom 1
23 333825 Door Weldment, E2 LH Hinge, Swing-out Insulated 1
--- xxxxxx Door Weldment, E2 LH Hinge, Swing-out Standard 1
--- xxxxxx Door Weldment, B30 RH Hinge, Swing-out Insulated 1
--- xxxxxx Door Weldment, B30 RH Hinge, Swing-out Standard 1
