CHAMPION EUCC Series - Manual (Page 198)

190
Control Cabinet (From S/N J2098 up to J08102541)
18 111833 Block, Terminal 185A 1
--- 109014 Block, Terminal 310A 1
19 111827 Contactor, Heat Electric 60A 3P A/R
20 180081 Transformer, Control 750VA, 208-240/480/60/3:120VAC 1
--- 112792 Transformer, Control 750VA 575/60/3:120VAC 1
21 112351 Timer, 0-6 minute 2
22 112352 Socket, Timer 2
23 111068 Relay, 120VAC 2
24 111036 Socket, Relay A/R
25 111067 Relay, 24VAC A/R
26 304326 Bracket, Switch 1
27 107198 Switch, Toggle (Bypass) 1
28 108370 Washer, Lock 1
29 104858 Nameplate, Automatic-Manual 1
30 111277 Transformer, Control 120VAC:24VAC 1
31 180171 Fuse Block 600V 35A to 60A A/R
32 111135 Fuse Block 600V 25A to 30A A/R
33 108424 Fuse Block 600V 70A to 100A A/R
34 111683 Fuse 30A J A/R
--- 180172 Fuse 35A J A/R
--- 180173 Fuse 40A J A/R
--- 180174 Fuse 45A J A/R
--- 180175 Fuse 50A J A/R
--- 180176 Fuse 60A J A/R
--- 180060 Fuse 70A T A/R
--- 180059 Fuse 80A T A/R
--- 180448 Fuse 90A T A/R
--- 180042 Fuse 100A T A/R
35 111980 Breaker, Circuit ON/OFF 5A 1
36 111614 Push button Start GREEN 1
37 111617 Block, Contact N.O. 1
38 113140 Boot, Silicon Push button 1
39 111615 Push button Stop RED 1
40 111616 Block, Contact N.C. 1
41 114117 Decal EUC 6/8 with Prewash L-R 1
--- 114159 Decal EUC 6/8 with Prewash R-L 1
--- 114286 Decal EUC 4 with Prewash L-R 1
--- 114287 Decal EUC 6/8 without Prewash L-R 1
--- 114307 Decal EUC 6/8 without Prewash R-L 1
42 112382 Relay 3PDT 120V, 10A 3
43 112415 Socket, Relay 3PDT 3
44 114413 Timer, 30 seconds 1
--- 900725 Kit, Push button GREEN (includes items 36,37,38) A/R
--- 900726 Kit, Push button RED (includes items 38,39,40) A/R
Item
No.
Part
No.
Qty. Description
