CHAMPION EUCC Series - Manual (Page 131)

123
Steam Coil Heat Installation C4 Wash, Rinse, 15-30 PSI
1 100002 BOLT, HEX HD. 1/4-20 X 1-3/8" SST 4
2 100007 SCREW, TRUSS HEAD, 10-32 X 3/8" SST 3
3 100023 STREET, ELBOW 3/4" NPT X 90° SST 1
4 100109 WELD STUD, 1/4-20 X 1/2" LG. SST 1
5 100134 ELBOW, STREET, 1" NPT X 90° MI 1
6 100147 ELBOW, STREET, 1/2" NPT X 90° MI 1
7 100154 HEX PLAIN NUT, 5/16-18 SST 8
8 100198 WELD STUD, 10-32 X 1/2" SST 4
9 100547 LOCKNUT, 1/2" NPT SST 1
10 100740 BOLT, HEX HD., 5/16-18 X 1" SST 8
11 102376 WASHER, FLAT 5/16" SST 16
12 102554 UNION, 3/4" NPT SST 2
13 105738 ELBOW, REDUCING 1" NPT X 1/2" NPT X 90° MI 1
14 105739 ELBOW, REDUCING, 1" NPT X 3/4" NPT X 90° MI 1
15 105778 UNION, 1/2" NPT MI 2
16 105780 UNION, 1" NPT MI 2
17 105782 NIPPLE, 1/2" NPT X CLOSE BI 1
18 105783 NIPPLE, 1/2" NPT X 2" LG. BI 1
19 105847 NIPPLE, 1" NPT X CLOSE BI 1
20 106013 WASHER, LOCK 5/16" SPLIT SST 8
21 106026 WASHER, FLAT 1/4" SST 2
22 106486 WASHER, LOCK #10 SPLIT, SST 2
23 107033 WASHER, FLAT .208" X .438" X .047" SST 4
24 107136 SCREW, HEX HD., 10-32 X 3/8" SST 2
25 107488 NIPPLE, 1/2" NPT X 3-1/2" LG. BI 1
26 107966 HEX GRIP NUT, 10-32 SST W/NYLON INSERT 4
27 107967 HEX GRIP NUT, 1/4-20 SST W/NYLON INSERT 2
28 108345 GASKET, HEATER/STANDPIPE 2
29 109069 THERMOSTAT, CONTROL WITH CAPILLARY 1
30 109580 NIPPLE, 1/2" NPT X 11" LG. BI 1
31 109969 NIPPLE, 1" NPT X 3-3/4" LG BI 2
32 110005 VALVE, 1" ASCO (NO LONGER AVAILABLE) 1
110007 REPAIR KIT, 1" ASCO VALVE # L8220G007 ONLY A/R
--- 114800 VALVE, 1" ASCO STEAM ASCO # L8220G410 1
114830 REPAIR KIT, 1" ASCO VALVE # L8SS0G410 ONLY A/R
33 111380 STEAM TRAP, 1/2" NPT TDC 1
34 201041 WASHER, SPACER 7/8" X 1-3/16" X 1/8" NP 1
35 323430 BRACKER, THERMOSTAT 1
36 329768 COVER, HEATER BOX C4-BKT 1
37 329769 HEATER BOX WELDMENT, C4-B 1
38 330129 STEAM COIL WELDMENT, C4-HP 1
39 330242 FLANGE, WELDMENT STEAM, C3/C4 HP 1
40 330243 FLANGE, WELDMENT, CONDENSATE C3/C4 HP 1
41 330362 BRACKET, WELDMENT C4, STEAM COIL 2
42 330363 CAP, DEVELOPMENT STEAM COIL BRACKET 2
