61) Female Wire Connector

b. Flange Bolt M6×16 6P

c. Flange Bolt M6×20 30P

d. Flange Bolt M8×12 3P

f. Flange Bolt M8×35 1P

g. Flange Bolt M8×45 1P

h. Flange Bolt M8×50 1 P

k. Hex Bolt M10 X 55 1P

l. Cap Bolt M6 X 15 2P

j. Hex Bolt M8 X 110 3P

o. Flange Nut M6 4P

p. Flange Nut M8 7P

63) SUS Power LM 1P

67) Compressor Plate 1P

69) Instruction Manual 1P

68) Access Computer 1P

n. Stud Bolt M8 2P

r. Washer M6 2P

s. Washer M8 2P

t. Washer M10 3P

65) Lock Tight 15P

a. Flange Bolt M6×8 1P

e. Flange Bolt M8×16 5P

i. Flange Bolt M10×35 4P

m. Cap Bolt M8×15 3P

q. Flange Nut M10 1P
