Page 7
Rev. B, 4/13
MPX Series Magnetostrictive Level Sensors
7
Automation Products Group, Inc.
APG...Providing tailored solutions for measurement applications
Tel: 1/888/525-7300 • Fax: 1/435/753-7490 • www.apgsensors.com • [email protected]
12-24 Vdc
Out 1
Out 2
Input 1 Input 2 Com
Receiver
Sensor
Sensor
Dual 4-20 mA Loop Wiring
(MPX-E3 and MPX-R3 Series)
Input Com
Receiver 1
Input Com
Receiver 2
OR
+
Power Source
(12-24 Vdc)
−
12-24 Vdc
Out 1
Out 2
Sensor
+
Power Source
(12-24 Vdc)
−
12-24 Vdc
Out
4-20 mA Loop Wiring
(MPX-E2 and MPX-R2 Series)
Input Com
Receiver
+
Power Source
(12-24 Vdc)
−
4-20 mA Loop Wiring
(MPX-E2, MPX-R2 and MPX-E3, MPX-R3 models)
