Rev. B, 4/13 MPX Series Magnetostrictive Level Sensors
17
Automation Products Group, Inc.
APG...Providing tailored solutions for measurement applications
Tel: 1/888/525-7300 • Fax: 1/435/753-7490 • www.apgsensors.com • [email protected]
(continued)
Register Function Value Range
40415 Sample Rate 50 to 1000 msec.
40416 Multiplier 1 to 1999
40417 Offset +/- 10364 mm
40418-40420 Reserved n/a
40421 RTD Offset ( 0 C) -100 to 100
40422 Float Window 0 to 1000 mm
40423 Top Float Offset -10364 to 10364
40424 Bottom Float Offset -10364 to 10364
40425 Gain Offset 0 to 255
40426 4 mA Set Point 0 to 10364 mm
40427 20 mA Set Point 0 to 10364 mm
40428 4 mA Calibration 0 to 1000
40429 20 mA Calibration 0 to 1000
40430 Web Alarm 1 Distance
40431 Web Alarm 1 Window
40432 Web Alarm 1 Type
40433 Web Alarm 2 Distance
40434 Web Alarm 2 Window
40435 Web Alarm 2 Type
40436-40437 Parameter 1 Data 0 to 100,000 mm
40438-40439 Parameter 2 Data 0 to 100,000 mm
40440-40441 Parameter 3 Data 0 to 100,000 mm
40442-40443 Parameter 4 Data 0 to 100,000 mm
40444-40445 Parameter 5 Data 0 to 100,000 mm
