To send all the register values as
currently listed, click “Send All”
A green window
indicates successful
communication.
A yellow window
indicates a communi-
cation failure.
To change an individual parameter, click on the value
you wish to change, enter the desired value, then click
the adjacent “Send” button to implement the change.
To retrieve the register values saved
in a sensor, click “Receive All”
1500 Send 1500 Send 150000 Send
A red window indi-
cates a value outside
the allowable limits
for the parameter.
