Rev. B, 4/13 MPX Series Magnetostrictive Level Sensors
43
Automation Products Group, Inc.
APG...Providing tailored solutions for measurement applications
Tel: 1/888/525-7300 • Fax: 1/435/753-7490 • www.apgsensors.com • [email protected]
Certificate: 2397437 Master Contract: 237484
Project: 2397437 Date Issued: May 18, 2011
DQD 507 Rev. 2009-09-01 Page: 2
Notes:
• The model code breakdown is as follows: a= E or R; b= 1, 2 or 3; c= A, B, C, D, E, F, Z, or Y; d= N, B, D, or
Y; e= F, R, P, N, or O; f= W or S; g= A or B; and hhh= 12–153 for the 1/2" stem or 48–300 for the 1" stem.
• The equipment is intended to be installed as required by the applicable electrical code (CEC, NEC) and as
specified by the manufacturers Installation Instructions.
• The installation will be inspected by the authority with jurisdiction in the area where installed.
APPLICABLE REQUIREMENTS
CSA C22.2 No 0-10 General Requirements – Canadian Electrical Code, Part
II – Tenth Edition
CSA C22.2 No 30-M1986 (R 2007) Explosion-Proof Enclosures for Use in Class I
Hazardous Locations Industrial Products – Third
Edition
CSA C22.2 No 142-M1987 (R 2009) Process Control Equipment Industrial Products – Third
Edition
CSA C22.2 No 213-M1987 (R 2008) Non-incendive Electrical Equipment for Use in Class I,
Division 2 Hazardous Locations Industrial Products –
First Edition
CSA C22.2 No 60079-0-07 Electrical apparatus for explosive gas atmospheres –
Part 0: General requirements – First Edition
CSA C22.2 No 60079-1-07 Electrical apparatus for explosive gas atmospheres –
Part 1: Flameproof enclosures "d" – First Edition
CSA E60079-15-02 (R 2006) Electrical Apparatus for Explosive Gas Atmospheres –
Part 15: Type of Protection "n" – Second Edition
UL 508 Industrial Control Equipment - Seventeenth Edition;
Reprint with Revisions Through and Including April
15, 2010
UL 1203 Explosion-Proof and Dust-Ignition-Proof Electrical
Equipment for Use in Hazardous (Classified) Locations
- Fourth Edition; Reprint with Revisions through and
Including October 28, 2009
ANSI/ISA-12.12.01-2007 Nonincendive Electrical Equipment for Use in Class
I and II, Division 2 and Class III, Divisions 1 and 2
Hazardous (Classified) Locations
MARKINGS
The following markings are provided on a UL Recognized (PGJI2) adhesive nameplate manufactured by
Datamax, type FantaStock-HCW, printed with a resin ribbon manufactured by Datamax, type Greatribbon
SDR or SDR-5, which is suitable for indoor/outdoor use on polyurethane paint coatings, at a maximum service
temperature of 135°C or higher. Alternatively a screw or rivet secured metal nameplate or other permanent
