INTRODUCTION
We thank you for purchasing the “A” AnchorSpan™ clearspan fabric structure from Anchor Industries Inc. The
AnchorSpan™ is designed to provide a balance between ease of installation and the aesthetic appeal of the
curved beam structural configuration.
This assembly manual is for all A AnchorSpans™, including 30’, 40’, 50’, 60’, 70’ and 80’ wide units. We
recognize that every installation site is unique with its own individual obstacles and requirements. For instance,
some sites may have very tight perimeter restrictions such as cyclone fences or existing permanent buildings.
Others may involve installing the AnchorSpan™ over a pool or mounting it on an elevated stage. Though we
cannot give detailed descriptions of every technique that may be needed for all possible unique situations, we
will be happy to share whatever insights we have from prior experience. Just call 1-800-544-4445 and talk with
our customer service representatives.
Some of the unique situations mentioned above may require specialized rigging or the use of motorized
equipment to lift or position beam components. however, for most typical situations, the fairly simple vertical or
telescopic forklift method of this manual should work fine. We caution that all power equipment should be
operated well within its safety limits by a qualified operator.
In the index, we show an alternate gin pole technique that can be adapted to any motorized vehicle with enough
power to pivot the beams. This gin pole is an adapted gable end upright frame member, which is later built into
the end framing of the structure. In the 70 ft and 80 ft structures, aerial lifts, such as scissor lifts or scaffolding
must be used to complete some of the higher attachments and lace the fabric end panels.
For Installations required to meet code certification.
In this installation manual, we describe an uncertified temporary installation using 42” tent stakes for anchoring.
NOTICE. If your application is permanent or semi-permanent (less than 180 days) or you are required to
meet code, you should consult with the building department of your local government offices to determine
what wind and snowload ratings are appropriate for your location. You should then contact Anchor Industries to
confirm whether your unit has been configured to meet those code requirements. Generally, anchoring with
standard tent stakes will not meet code. Depending upon load ratings, permanent anchoring will require at
least one of the following:
1. Multiple Staking — consult with Anchor Industries regarding baseplate extenders for multiple staking.
2. Concrete pier-footings — Anchor supplies base load reactions that will enable your local concrete
contractor to design and specify proper footings and anchor bolts.
3. Earth anchors — you can obtain Duckbill and Manta Ray earth anchors from Foresight
Products LLC, phone 1-(800) 325-5360, fax #(303) 287-3866. Adapter plates may be necessary
to allow the AnchorSpan™ base plates to use these permanent earth anchors.
4. Others as may be defined by your local professional engineer.
NOTICE: It is the customer’s responsibility to obtain all necessary permits and to select the proper anchoring
devices required to properly anchor this structure in conformance with local codes.
