X-6
“A” ANCHORSPAN™ COMPONENT WEIGHTS & MEASURES
[ ] indicates items that stack easily
within each other’s shape
Part/Assembly Description
Weight
Dimensions Volume
Packing Comments/Suggestions
Lbs. Ea.
(Nominal)
in cu. ft.
(Dimensions are to widest points)
Base Column Assembly
140
4”x4’8”x17’9”
[27.6}
4’8” is measured across the curve
Apex Assembly
130
4”x4’8”x14’7”
[13]
Stacks within the curve of base column
40’ Rafter Assembly
48
4”x7”x6’4”
2.8
Includes splice in male end
50’ Rafter Assembly
83
4”x7”x118”
2.3
Includes splice in male end
60’ Rafter Assembly
131
4”x7”x17’
3.3
Includes splice in male end
Baseplate
38
18”x21”x6”
[1]
Sandwich 2 in space of approx. 1
Baseplate Adapter Bar
3.4
2’x2”x15’
0.04
Pack in drum with other loose items
SpanLatch Purlin
26
3”x6”x15’4”
2.1
Protect latching ends
Double SpanLatch Purlins
27
3”x6”x15’4”
2.1
Protect latching ends
Purlin Bolt Assemblies
1.8
2”x2”x10”
0.02
Pack pre-assembled in drum
End Beam Blot Assemblies
2.4
2”x6”x10”
0.09
Pack pre-assembled in drum
Upright Bracket Bolt Assembly
2.7
3”x4”x10”
0.07
Pack pre-assembled in drum
Wing Eave Brackets
0.034
2”x2”x1”
0.003
Store with end beam bolt assemblies
Mid Eave Bars 15’
29
2”x4”x14’11”
0.83
All eave bars stack well together
End Eave Bars 20’
40
2”x4”x19’11”
1.1
All eave bars stack well together
Wing Eave Bar 10’ (Left)
18
2”x4”x8’10”
0.5
All eave bars stack well together
Wing Eave Bar 10’ (Right)
18
2”x4”x8’10”
0.5
All eave bars stack well together
Wing Eave Bar 15’ (Left)
29
2”x4”x13’9”
0.8
All eave bars stack well together
Wing Eave Bar 15’ (Right)
29
2”x4”x13’9”
0.8
All eave bars stack well together
Midwall Ground Bar 15’
16
X”x1”x 15’3”
0.1
Easily strapped together in bundles
Endwall Ground Bar 20’
22
X”x1”x 20’3”
0.14
Easily strapped together in bundles
Wingwall Ground Bar 10’
10
X”x1”x 9’4”
0.06
Easily strapped together in bundles
Wingwall Ground Bar 15”
16
X”x1”x 14’4”
0.1
Easily strapped together in bundles
End Upright, Short
78
4”x7”x15’3”
3
(at shortest adj) Store fully assembled
End Upright, Long
108
4”x7”x21’8”
4.2
Store fully assembled
Bent Arm Pin
0.64
1”x1”x10”
0.004
Pack in drum with hair pin cotters
#10 Hair Pin Cotter
0.03
A“x1”x3”
0.0002
Pack installed on bent arm pins
Fabric Tensioning Winch
2.9
3”x4”x9”
0.07
Pack in drum or similar
42” Shoulder Hd. Steel Stakes
12.8
2”x2”x43”
0.13
Pack in drum or similar
24”x1” Steel Stakes
2.1
1Z”x1Z”x25”
0.02
Pack in drum or similar
End Center Bar, 40’
5.1
2”x3”x9’3”
0.4
Stack with eave bars and ground bars
End Center Bar, 50’
8.0
2”x3”x11’
0.5
Stack with eave bars and ground bars
End Center Bar, 80’
10.0
2”x3”x17’
0.5
Stack with eave bars and ground bars
Cross-Cable/ Green
4.2
Coiled
0.4
Pack all together in drum or similar
Cross-Cable/ Red
4.1
Coiled
0.4
Pack all together in drum or similar
Cross-Cable/ Blue
4.7
Coiled
0.5
Pack all together in drum or similar
Stake Bar 2’ (3-holed)
5.4
2”x2”x2’
0.06
Pack with loose hardware
Century Guy Winch
6.4
4”x4”x5”
0.05
Pack with loose hardware
AnchorSpan Installation Kit:
15”x4”x20’
8.3
Kit below shipped in 1 container
Long Purlin Hook
1X”x11”x20’
incl.
Shipped included in installation kit above
Short Purlin Hook
1X”x11”x12’6”
incl.
Shipped included in installation kit above
Diagonal Beam Brace
2”x2”x17’3”
incl.
Shipped included in installation kit above
Beam Hook & Harness
incl.
Shipped included in installation kit above
Fabric Hook & Harness
incl.
Shipped included in installation kit above
Eave Bar Cradle
incl.
Shipped included in installation kit above
Eye Fittings for Gin Pole
incl.
Shipped included in installation kit above
