4
Mid-Eave Bar Bracket
Wing Eave
Bracket
42” Double Hd.
Stake
Fabric Tensioning
Winch
Beam Hook
& Harness
(12 Items)
Eave Bar
Cradles
Diagonal Beam
Braces
Eave Bar
Cross Section
Ground Bar
End Slot
ANCHORSPAN INSTALLATION KIT
2’ Stake Bar &
Century Winch
Cross-Cables
Color Coded
Purlin Tools
AA Baseplate
AA Baseplate Adapter Bar
Bent Arm Pin
#10 Hair Pin Cotter
SpanLatch Purlin
Dbl-SpanLatch Purlin
AA End Eave Bar Assembly 20’
AA Mid Eave Bar Assembly 15’
NOTE: WING EAVE BARS ARE LEFT OR RIGHT
AA Wing Eave Bar Assembly 15’
AA Wing Eave Bar Assembly 10’
Endwall Ground Bar 20’
Midwall Ground Bar 15’
Wingwall Ground Bar 15’
Wingwall Ground Bar 10’
End Upright
Assemblies with
24” Stakes
AA Base
Column
Assembly
Male End w/Splice
at Top
40’ Rafter
Assembly 50’ Rafter
Assembly
60’ Rafter
Assembly
Apex Assembly
(Both ends are female)
Purlin Bolt Assembly
End Beam Bolt Assembly
Upright Bracket Bolt Assembly
AA Extrusion for
Beam & End Upright
Gabled End
Center Bars
Top
40’
50’
Long
Internal
Splice
Male Ends w/Splice
Point toward Apex
AA ANCHORSPAN™
COMPONENT ILLUSTRATIONS
Short
Eye Fittings
(for Gin Pole)
Fabric Hook
& Harness
