AA ANCHORSPAN™ COMPONENT WEIGHTS & MEASURES

[ ] indicates items that stack easily
within each other’s shape

Part/Assembly Description

Weight Dimensions Volume

Packing Comments/Suggestions

Lbs. Ea. (Nominal)

in cu. ft. (Dimensions are to widest points)

Base Column Assembly

4”x4’8”x17’9” [27.6}

4’8” is measured across the curve

Apex Assembly

4”x4’8”x14’7” [13]

Stacks within the curve of base column

40’ Rafter Assembly

4”x7”x6’4” 2.8

Includes splice in male end

50’ Rafter Assembly

4”x7”x118” 2.3

Includes splice in male end

60’ Rafter Assembly

4”x7”x17’

3.3

Includes splice in male end

Baseplate

16”x18”x6” [1]

Sandwich 2 in space of approx. 1

Baseplate Adapter Bar

3.4

2’x2C”x15’ 0.04

Pack in drum with other loose items

SpanLatch Purlin

3”x6C”x15’4” 2.1

Protect latching ends

Double SpanLatch Purlins

3”x6C”x15’4” 2.1

Protect latching ends

Purlin Bolt Assemblies

1.8

2”x2”x10”

0.02

Pack pre-assembled in drum

End Beam Blot Assemblies

2.4

2C”x6”x10” 0.09

Pack pre-assembled in drum

Upright Bracket Bolt Assembly 2.7

3”x4”x10”

0.07

Pack pre-assembled in drum

Wing Eave Brackets

0.034 2”x2”x1C” 0.003

Store with end beam bolt assemblies

Mid Eave Bars 15’

2”x4”x14’11” 0.83

All eave bars stack well together

End Eave Bars 20’

2”x4”x19’11” 1.1

All eave bars stack well together

Wing Eave Bar 10’ (Left)

2”x4”x8’10” 0.5

All eave bars stack well together

Wing Eave Bar 10’ (Right)

2”x4”x8’10” 0.5

All eave bars stack well together

Wing Eave Bar 15’ (Left)

2”x4”x13’9” 0.8

All eave bars stack well together

Wing Eave Bar 15’ (Right)

2”x4”x13’9” 0.8

All eave bars stack well together

Midwall Ground Bar 15’

X”x1”x 15’3” 0.1

Easily strapped together in bundles

Endwall Ground Bar 20’

X”x1”x 20’3” 0.14

Easily strapped together in bundles

Wingwall Ground Bar 10’

X”x1”x 9’4” 0.06

Easily strapped together in bundles

Wingwall Ground Bar 15”

X”x1”x 14’4” 0.1

Easily strapped together in bundles

Adjustable End Upright

4”x7”x15’3” 3

(at shortest adj) Store fully assembled

End Upright for 60’

108

4”x7”x21’8” 4.2

Store fully assembled

Bent Arm Pin

0.64

C”x1C”x10” 0.004

Pack in drum with hair pin cotters

#10 Hair Pin Cotter

0.03

A“x1”x3”

0.0002 Pack installed on bent arm pins

Fabric Tensioning Winch

2.9

3”x4”x9C”

0.07

Pack in drum or similar

42” Shoulder Hd. Steel Stakes 12.8

2Z”x2Z”x43” 0.13

Pack in drum or similar

24”xD” Steel Stakes

2.1

1Z”x1Z”x25” 0.02

Pack in drum or similar

End Center Bar 40’

5.1

2”x3”x9’3” 0.4

Stack with eave bars and ground bars

End Center Bar 50’

6.2

2”x3”x10’10” 0.5

Stack with eave bars and ground bars

Cross-Cable/ Green

4.2

1C”x2”x17’5” 0.4

Pack all together in drum or similar

Cross-Cable/ Red

4.1

1C”x2”x17’

0.4

Pack all together in drum or similar

Cross-Cable/ Blue

4.7

1C”x2”x21’5” 0.5

Pack all together in drum or similar

Cross-Cable/ Yellow

4.3

1C”x2”x18’

0.4

Pack all together in drum or similar

Cross-Cable/ Black

1C”x2”x15’6” 0.3

Pack all together in drum or similar

Stake Bar 2’ (3-holed)

5.4

2”x2”x2’

0.06

Pack with loose hardware

Century Guy Winch

6.4

4”x4”x5”

0.05

Pack with loose hardware

AnchorSpan Installation Kit

15”x4”x20’

8.3

Kit below shipped in 1 container

Long Purlin Hook

1X”x11”x20’ incl.
