Anchor ANCHORSPAN AA 30FT-60FT - Manual (Page 32)

X-7
END UPRIGHT BASE PLATE
SIDE BASE PLATE
CENTER
SPOTTING
HOLE
AnchorSpan “AA” TEMPLATE DRAWING
FOR SIDE AND END UPRIGHT BASE PLATES
1’- 6”
1’- 2”
7/8” DIA.
7”
2”
4”
4”
5 1/2”
7 1/2”
7 1/2”
9”
TO INSIDE OF STRUCTURE
SIDE LINE OF STRUCTURE
INSIDE & OUTSIDE
8 1/2”
10”
8 1/2”
1’- 8”
