Configuration
3.3
59
- Not registered – 2N
®
Helios IP is not registered to the SIP
proxy.
Registration at – the IP address or domain name of SIP proxy to which 2N
®
Helios IP
is registered.
Registration time – registration date and time.
Call state – the current call status:
- Inactive – system inactive;
- Call set-up – call being set up;
- Ringing – ringing at VoIP phone;
- Incoming – VoIP phone-to-2N
®
Helios IP call being set-up;
- Outgoing – 2N
®
Helios IP-to-VoIP phone call being set-up.
Opponent – displays the SIP address called from 2N
®
Helios IP.
Call duration – the current call duration.
Audio codec – the audio codec used for the current call.
Video codec – the video codec used for the current call.
DHCP status – displays whether the obtaining of the IP address from the DHCP
server is on.
IP address – the current IP address of 2N
®
Helios IP.
Net mask – the current subnet mask.
Default gateway – the current default network gateway.
Primary DNS – the current primary Domain Name Server.
Secondary DNS – the current secondary Domain Name Server.
Ethernet frames transmitted – the count of Ethernet frames transmitted.
Ethernet frames received – the count of Ethernet frames received.
Ethernet frames dropped – the count of Ethernet frames dropped due to damage.
UDP packet transmitted – the count of UDP packets transmitted.
UDP packet received – the count of UDP packets received.
UDP packet dropped – the count of UDP packets dropped due to damage.
TCP packet transmitted – the count of TCP packets transmitted.
TCP packet received – the count of TCP packets received.
TCP packet dropped – the count of TCP packets dropped due to damage.
