SECTION 2 - TURNTABLE
3121617
600A/600AJ
87
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
54
7021212
1
Journal, Bearing
55
7021232
1
Seal, Lip
56
7021232
1
O-Ring
57
7010121
1
Shaft, Main Pump
58
7021214
1
Plate, Valve
59
7007463
1
Gerotor Assembly
60
7007464
1
Pin
61
7007465
1
Key, Woodruff
62
7007466
1
Adaptor, Remote Filtration (Without By-Pass)
64
7021218
3
Screw
67
7021220
1
Cover, Servo (Without Adjuster)
68
7021219
1
Cover, Servo (Without Adjuster)
69
7023979
1
Guide, Spring
70
7007484
1
Stop, Servo
71
7007485
1
Spring
72
7021221
1
Screw
73
7007487
1
Guide, Spring
74
7007488
1
Ring, Retaining
75
7021222
1
Locknut
76
See Note
2
Ring, Piston (Note: Use Item 101A or 101B)
77
7007494
1
Piston, Servo
78
See Note
2
O-Ring (Note: Use Item 101A or 101B)
79
7007472
1
Valve, Bypass
80
7024851
2
Valve, Pressure Relief (Includes Item 6)
81
7007474
1
Control, Dual Oil-Filled
81
7007496
1
Coil Assembly (Pilot)
81
7007497
1
Plug (Pump)
81
7007498
1
Plug (Valve Harness)
82
7001498
2
Screw
83
7007478
2
Screw
84
7001433
2
O-Ring
86
7007475
1
Plug, Orifice/Screen (.156)
87
7007477
2
Plug, Orifice (.37)
88
7007476
1
Adapter, Auxiliary Pump
89
7021217
1
Spacer/Gasket
90
7021206
1
Nut
91
7024800
2
Spring
92
7021201
1
Bracket, Lifting
101
Ref
Seal Kit Options:
101A
7021232
1
Seal Kit - Complete (Includes Items 3, 6, 14, 37, 41, 42, 44, 45,
55, 56, 76, 78 & 89)
101B
7007412
1
Seal Kit - Servo Piston (Includes Items 76 & 78)
102
7010116
1
Cylinder Block Kit (Includes Items 19-28, & 50)
Ref
PISTON PUMP AND FITTING ASSEMBLY
3600396
Ref
Deutz Engine Machines
C
1001093410
Ref
GM Engine Machines
A
201
2220377
1
Fitting, Straight
202
Ref
Fitting, 90 Options
202
2220578
1
3600396 Pump
202
8770157
1
1001093410 Pump
203
2220646
2
Fitting, 90
204
2220947
2
Fitting, Straight
