SECTION 5 - CYLINDER
3121617 600A/600AJ 197
FIGURE 5-6. LIFT CYLINDER ASSEMBLY - TOWER BOOM
ITEM PART NUMBER QTY DESCRIPTION REV
1683288 Ref LIFT CYLINDER ASSEMBLY - TOWER BOOM M
1 1684017 1 Barrel
1A 0961949 2 Bushing, Composite
2 1684019 1 Rod
2A 0961949 2 Bushing, Composite
3 3480216 1 Piston
4 1683069 1 Head
5 0961899 1 Bushing, Tapered
6 4566667 1 Spacer
7 4640605 1 Cartridge, Valve
7 2900792 1 Seal Kit - 4640605
8 2220888 1 Plug, O-Ring #12
9 3760384 1 Ring, Washer
10 3932240 8 Capscrew, Socket Head 3/4in-10NC x 2-1/2in
11 0100011 AR Compound, Locking
12 0100038 AR Primer, Locking
13 2901322 2 Seal
14 2901322 2 Ring, Lock
15 2901322 1 O-Ring
16 2901322 1 Ring, Back-Up
17 2901322 3 Ring, Wear
18 2901322 1 O-Ring
20 2901322 1 Seal, Rod
21 2901322 1 Wiper
23 2220883 2 Plug, O-Ring #4
24 4640509 1 Counterbalance
24 2900792 1 Seal Kit - 4640509
25 0630536 3 Bolt 3/8in-16NC x 1-1/2in
26 0100063 AR Adhesive
51 2901322 1 Seal Kit (Includes Items 13-21)
